Detección De Movimiento 2.0
Human/Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type is supported;
Recording
Compresión De VídeoH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Resolución De Codificación
For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF
For 720p stream access: 720p/WD1/4CIF/VGA/CIF
For standard definition stream access: WD1/4CIF/VGA/CIF
Frame Rate
Main stream:
For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps
For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps
For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
Sub-stream:
For 1080p and 720p stream access CIF/QVGA@15 fps
For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N)
Vídeo Bitrate32 Kbps to 4 Mbps
Doble FlujoSupport
Stream TypeVideo, Video & Audio
Compresión De AudioG.711u
Audio Bitrate64 Kbps
Video And Audio
Entrada De Vídeo IP
2-ch (up to 18-ch)
Up to 5 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
Entrada De Video Analógico
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input1080p25, 1080p30, 720p25, 720p30
AHD Input1080p25, 1080p30, 720p25, 720p30
HDCVI Input1080p25, 1080p30, 720p25, 720p30
CVBS InputPAL/NTSC
HDMI Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Video Output ModeHDMI/VGA simultaneous output
Entrada De Audio1-ch RCA (2.0 Vp-p, 1 KΩ), and 16-ch via coaxial cable
Salida De Audio1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Reproducción Sincrónica16-ch
Red
Total Bandwidth96 Mbps
Conexión Remota128
Protocolo De RedTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Interfaz De Red1, RJ45 10M/100M self-adaptive Ethernet interface
Auxiliary Interface
SATA1, SATA interface
CapacidadUp to 10 TB capacity for each disk
Interfaz USB2 × USB 2.0
General
Fuente De Alimentación12 VDC, 1.6 A
Consumo≤ 7 W (without HDD)
Temperatura De Trabajo-10 °C to 55 °C (14 °F to 131 °F)
Condiciones De Humedad10% to 90%
Dimensión (W × D × H)285 × 210 × 45 mm (11.2 × 8.3 × 1.8 inch)
≤ 1.8 kg (without HDD, 4.0 lb.)
